UNIT 1
is a small Production truck
Production
2 Tier Production Area
14 - input Miranda Multiviewer at Front Prod Desk across 2 Sony monitors

Video
Grass Valley Kayak 100C HD Switcher
24 input,  1 ME, 4 Internal DVE
6 Ch Ram Recorder/Still Store
4 keyers
10 Aux outs

Cameras
Sony HXC 100K HD Cameras (Studio & HH)
Fujinon 20X Box Lenses
Fujinon 55X Box Lense
Canon 19X ENG Lense
Canon 16X HD ENG Lense
4 - Quickset sticks
2 - Vinten ENG sticks

Recording
1 - 6x1or 4x2 Grass Valley K2 Summit/Dyno Record and Player Slo-Mo.
1 - 2x1 grass Valley K2 Solo/Dyno Record and Player Slo-Mo.
2 - KiPro HD hard disc recorder
14 Input Multiviewer in recording area

Audio
Yamaha LS-9 24x16 audio board
6 - Audio DA's
1 - 360 Systems Digicart
1 - CD  Player
4 - DBX compressors
4 - Telos telephone hybrids
1 - Gentner telephone interface
2 - Daltech Announce Boxes
4 - Audio Technica Shotguns
6 - Hand Mics, RE-50, EV635, SM58
6 - Shure Lav Mics & Sportscaster Headsets Routing
10 - Aux buses off Kayak
AJA Kumo 16x16 sd/hd-sdi Router

Graphics
Chyron SDI Duet LEX

Communications
RTS 6 channel intercom system
RTS 4 channel IFB system
RTS 612 SAP Panel
10 - BP 300 Intercom Beltpacks
6 - IFB Beltpacks
4 - Motorola Radios
4 - Line telephone system


Terminal
4 - AJA FS1 Frame Syncs
3 - AJA FR2 frames with various DA & convertor cards

Power
240V single phase
50 amps
3 -  AC units

Overall Dimensions
8'x23' GMC Production Truck
8'x19'  "B" unit trailer
12'6" Height The Truck has three work areas:

Production:  work areas for the Director, TD, Video Shader, Chyron Op, Producer and Client.

Audio:  Yamaha LS-9 mixer and all  the support equipment needed with a full view of the production area.

Record area:  accommodates various recording media, including tape or digital record and playback.
AUDIO
Production
Record/Playback
