1. •2 or 4 SD/HD channels
2. •2 or 4 bi-directional HD/SD-SDI record/play channels
3. •SD SDI: SMPTE 259M, ITU R601, 525/625 line component, 10-bit
4. •HD-SDI: SMPTE 292M, 10-bit

1. •DV, DVCAM, DV25, DV50
2. •MPEG-2@ML 4:2:0, I-Frame & Long GOP 2-15 Mb/s
3. •MPEG-2 @ML 4:2:2, I-Frame & Long GOP 4-50 Mb/s

1. •MPEG-2@HL 4:2:0, I-Frame & Long GOP 12-100 Mb/s
2. •MPEG-2 @HL 4:2:2, I-Frame & Long GOP 20-100 Mb/s
3. •XDCAM HD (18, 25, 35 Mb/s)
4. •XDCAM HD 4:2:2 (50 Mb/s)
5. •XDCAM EX
6. •DVCPRO HD
7. •AVC-Intra 50/100 (optional)
8. •H.264/AVCHD playback (optional)

1. •Multicam (up to 4 channels)
2. •Super slo-mo (1 or 2 channels)
3. •3D (up to 4 channels)
4. •Video+key (up to 4 channels)

1. •Scrub audio support (±2X)
2. •Audio click elimination
3. •Agile playback of clips with different supported audio formats
4. •Audio tagging and audio mapping
5. •Audio mix effects (PCM only)
6. •Cross fade between tracks
7. •Fade up/down

1. •SDI monitor out w/timecode burn-in
2. •VGA multiviewer – w/definable text overlay for above displays including channel name, clip name, transport status, play speed, audio meters, and other status

1. •Any supported format can be played seamlessly back-to-back
2. •Output can be delayed at pixel resolution within a range of one frame
3. •Freeze mode: frame or field
4. •Off-speed play: line interpolation provides jitter free slow-motion playback in both directions

1. •Dissolves between two video tracks on same channel
2. •Fade up/down to matte color (default is black)
3. •Max duration per transition: user selectable

1. •525-1080i, 525-720p, 625-1080i, 625-720p, 720p-1080i cross conversion
2. •AFD support for 4:3-16:9 aspect ratio conversion with format specified on a channel basis with clip-by-clip override capability
3. •Bar, half-bar, crop, and stretch options configurable via UI, AMP protocol, or K2.net
4.

1. •Less than one frame delay
2. •No re-timing applied

1. •Record or play up to 16 tracks per channel
2. •32 audio tracks per clip stored on disk

1. •16 tracks embedded, per video channel

1. •NTSC/PAL black composite analog
2. •Two BNC, 75Ω passive loop through
3. •Burst frequency lock: PAL, +10 Hz at subcarrier NTSC, +20 Hz at subcarrier
4. •Tri-Level sync conforms to SMPTE 296M-2001 for 1280x720P systems and SMPTE 274M-2008 for 1920x1080

1. •LTC SMPTE 12M, one per channel
2. •One mini-XLR per input and one mini- XLR with input and output
3. •1 kΩ input, 50Ω output impedance
4. •One VITC reader/writer per video:
5. •Lines 10-21 on 525 configurations, lines 6-23 on 625 configurations
6. •Ancillary timecode
7.

1. •Four RS-422 serial ports
2. •100/1000Base-T Ethernet port

1. •BVW (RS-422) (w/o insert edit)
2. •VDCP (RS-422)
3. •AMP (RS-422 and Ethernet)
4. •K2.net native API

1. •MXF Op1a, GXF (SMPTE 360M), AVI, and QuickTime

1. •Dual redundant 600W maximum, 400W typical
2. •Auto-sensing, hot-swap
3. •100-240 VAC, 50-60 Hz

1. •Operating temperature: 10° to +40°C (50° to 104°F)
2. •Non-operating temperature: -40° to +60°C (-40° to 140°F)
3. •Operating relative humidity: 20% to 80% from -5° to +45°C (23° to 113°F)
4. •Non-operating relative humidity: 10% to 80% from -30° to +60°C (-22° to 140°F)

1. •12 in, 12 out: 25-pin D connector (DB25)

1. •Height: 9 cm (3.5 in.) – 2 RU
2. •Width: 44.5 cm (17.5 in.)
3. •Depth: 61.6 cm (24.5 in.)
4. •Weight: 24 kg (53 lbs.) maximum
